ZEMIC
DHM9Bd10 ZEMIC Digital Load Cell
Model: DHM9Bd10
Digital Load Cell
10 / 20 / 25 / 30 / 40 / 40tLE / 50 t
Rated Capacity
OIML R60 C3
Accuracy Class
120% F.S
Safe Overload
DHM9Bd10 is a ZEMIC digital load cell for truck scale systems. It supports RS485 communication, long transmission distance, self-diagnosis, and IP68 protection for reliable digital weighing installations.
Key Features
- Digital RS485 output; self-diagnosis; remote communication; anti-cheating support; IP68 protection.
Applications
Truck Scale
Technical Specifications
Rated Capacity
10 / 20 / 25 / 30 / 40 / 40tLE / 50 t
Accuracy Class
OIML R60 C3
Rated Output
Digital output, 1,000,000 counts
Combined Error
<= +/-0.020% F.S
Creep
<= +/-0.016% F.S / 30 min
Temperature Effect
Output <= +/-0.011% F.S /10℃; zero <= +/-0.019% F.S /10℃
Temperature Range
Compensated -10 to +40℃; operating -20 to +60℃
Safe Overload
120% F.S
Ultimate Overload
150% F.S
Excitation Voltage
5.4-15 VDC
Protection Class
IP68
Material
Alloy Steel, Nickel-plated
Cable
Six-core shielded cable, 6.2 mm dia.; 16 m
Wiring / Interface
RS485, 4-wire; 19200 bps; max 32 nodes; up to 1000 m
Dimensions
240 mm * 135 mm * 195 mm
