H8C ZEMIC Single Point Load Cell
Model: H8C
Single Point Load Cell
0.5 / 1 / 1.2 / 2 / 2.5 / 3 / 5 / 10 t; 1-20 klb
Rated Capacity
C3 / C4 / C5 / A5M / B10M
Accuracy Class
150% F.S
Safe Overload
H8C is a ZEMIC single point load cell for floor scales and pallet truck scales. It offers a wide capacity range, OIML accuracy options, IP67 protection, and alloy steel construction for stable industrial weighing.
Key Features
- OIML approved; IP67 protection; alloy steel body; single point structure; suitable for floor scale and pallet truck applications.
Applications
Floor ScalePallet Truck Scale
Technical Specifications
Rated Capacity
0.5 / 1 / 1.2 / 2 / 2.5 / 3 / 5 / 10 t; 1-20 klb
Accuracy Class
C3 / C4 / C5 / A5M / B10M
Rated Output
3.0 +/-0.003 mV/V or 2.0 +/-0.002 mV/V
Combined Error
<= +/-0.010 to +/-0.050% F.S by class
Creep
<= +/-0.016 to +/-0.030% F.S / 30 min
Temperature Effect
Zero/span <= +/-0.008 to +/-0.040% F.S / 10 degC by class
Temperature Range
Compensated -10 to +40℃; operating -35 to +75℃
Safe Overload
150% F.S
Ultimate Overload
300% F.S
Excitation Voltage
5-12 VDC recommended; 18 VDC max
Protection Class
IP67
Material
Alloy Steel
Cable
4m for 0.5-2 t / 6m for higher
Wiring / Interface
4-wire: Exc+ red, Exc- black, Sig+ green, Sig- white, shield transparent
Dimensions
130 mm * 31.8 mm * 31.8 mm<br /> 171.5 mm * 38.1 mm * 38.1 mm<br /> 222.3 mm * 50.8 mm * 50.8 mm
