HF208 Weighing Indicator

Explore HEAVYE Indicator specifications and connection requirements for your weighing application.

HF208 · View 1

01 / 04

Select a view. Click the main image to enlarge.

From weight to useful information.

Review the display, operating functions and connections that bring weighing data into your workflow.

6-digit 1.85 inch/47 mm LED display

RS232; RS485; BLE; RF; 20 mA loop; 0-10 V; PS/2. Confirm the required interface in your configuration.

Basic weighing / Check-weighing / Ticket printing / Report printing / Barcode/QR/bitmap printing

For your daily workflowBench ScaleFloor ScaleCheckweighing

Configure your equipment

Select your communication and application requirements. We can discuss the functions and configuration your system needs.

Required communication

Application

Final specifications, connections and configuration are confirmed together for your application.

Select your requirements above.

Technical specifications
Model & display
Model	HF208
Brand	HEAVYE
Display	6-digit 1.85 inch/47 mm LED display
Housing	SS304 stainless steel housing and SS304 U-type bracket
Input & communication
Signal input	analog load cell signal
Load cell support	Up to 16 x 350 ohm load cells; single 4-wire/6-wire load cell application
Excitation voltage	DC 5 V
Measurement rate	10 measurements/s
Communication	RS232; RS485; BLE; RF; 20 mA loop; 0-10 V; PS/2
Power & operation
Power supply	Universal 100-240 Vac
Battery	Built-in 3.7 V / 4 Ah rechargeable lithium battery
Printer / version	Built-in 58 mm thermal
Key functions	Basic weighing / Check-weighing / Ticket printing / Report printing / Barcode/QR/bitmap printing
Optional expansion	SS304 T-type pole bracket / External PS/2 keyboard / RS485 / Bluetooth BLE / Analog output
Dimensions	250 x 205 x 60 mm
